Technical data
| Processor | |
| CPU | - Intel® Celeron™ J3455, QC, 10W - Intel® Core™ i3-7100U , DC, 15W - Intel® Core™ i5-7300U, DC, 15W |
| Frequency | 1.5 GHz~2.6 GHz (depends on CPU) |
| L2 Cache | 1Mb~ 3Mb (depends on CPU) |
| CPU Type | BGA |
| Chipset | SoC |
| BIOS | AMI |
| RAM | |
| Technology | Intel® Celeron™ J3455: - DDR3L 1866/1600MHz Intel® Core™ i3-7100U/i5-7300U: - DDR4 2133Mhz |
| Max. Capacity | Intel® Celeron™ J3455: - Up to 8GB Intel® Core™ i3-7100U/i5-7300U: - Upt to 16GB |
| Socket | Intel® Celeron™ J3455: - 1 x 204-pin SO-DIMM Intel® Core™ i3-7100U/i5-7300U: - 1 x 260-pin SO-DIMM |
| Display | |
| Controller | Intel® HD Graphics |
| GPU Capacity | Depends on CPU |
| Multiple Display | 3 independent displays |
| Interface | Intel® Celeron™ J3455: - HDMI up to 3840 x 2160 @30Hz - DP up to 4096 x 2160 @60Hz - LVDS up to 1920 x 1200 @60Hz Intel® Core™ i3-7100U/i5-7300U: - HDMI 1.4 up to 4096 x 2160 @24Hz - DP up to 4096 x 2160 @60Hz (Wsparcie DP++) - LVDS up to 1920 x 1200 @60Hz |
| Ethernet | |
| Controller | Intel® Celeron™ J3455: - 2x Intel® L211-AT GbE LAN Intel® Core™ i3-7100U/i5-7300U: - 1x Intel® L210-AT GbE LAN - 1 Intel® L219-LM GbE LAN PHY |
| TPM | |
| Controller | - |
| Expansion slots | |
| Mini-PCIe | 2x Full-size (w/mSATA, w/NANO SIM) |
| Mass memory | |
| SATA | 1 x 2.5" HDD/SSD |
| mSATA | 1 x Full-size |
| I/O | |
| RJ-45 | 4 |
| Audio | 1 x Mic-in 1 x Line-out |
| USB | 2 x USB 2.0 4 x USB 3.2 Gen 1 |
| Serial | 6x COM COM1&2: RS-232/422/485 COM3-6: RS-232 |
| GPIO | 16-bit (8xGPI, 8xGPO), 5V |
| HDMI | 1 x |
| DVI | 1 x (optional) |
| Display Port | 1 x |
| Antena | 4 x |
| Power supply | |
| DC Input | 1x 12~24VDC DC |
| Environment | |
| IP Rating | N/A |
| Working temp. | HDD: -10°C ~ 45°C SSD: -10°C ~ 55°C |
| Humidity temp. | 10 ~ 90%, non-condensing |
| Storage temp. | -20 ~ 80°C |
| Storage hum. | 10 ~ 90%, non-condensing |
| Vibration | IEC61373, cat 1, class B |
| Shock | IEC61373, cat 1, classB |
| Dimensions | |
| Dimensions (W. x D. x H.) | 200 x 150 x 55 mm |
| Weight | 1.39 kg |
| Mounting | Wall-mount, VESA |
| Certificates | |
| EMC | CE, FCC, VCCI, BSMI |
| Safety | BSMI |
| Operating System | |
| OS Support | Intel® Celeron™ J3455: Windows 10 IoT Enterprise LTSC/SAC 1809 (64-bit, RS5) Windows 10 IoT Core (32/64-bit) (by request) Linux Kernel 4.19 (64-bit) (by request) Intel® Core™ i3-7100U/i5-7300U: Windows 10 IoT Enterprise LTSC/SAC 1809 (64-bit, RS5) Linux Ubuntu 18.04 LTS (by request) Linux Kernel 4.14 (64-bit) (by request) |
