Technical data
| System procesor | |
| CPU | 12th Gen Intel® Mobile Alder Lake-P U-series Core™ i5/i3/ Celeron® Processor, DC, 15W |
| Frequency | 1.0 GHz~4.4 GHz (Depends on CPU) |
| L2 Cache | 8MB~12MB (Depends on CPU) |
| CPU Type | BGA |
| Chipset | Integrated |
| BIOS | AMI |
| Memory | |
| Technology | Dual-channel DDR4 3200 MHz |
| Max. Capacity | Up to 64GB |
| Socket | 2 x 260-pin SO-DIMMs |
| Graphic | |
| Controller | Intel® Iris® Xe Graphics (For i5 SKUs) Intel® UHD Graphics (For i3/Celeron SKUs) |
| Graphic Memory | Depends on CPU |
| Multiple Display | 4 independent displays |
| Display Interface | HDMI 2.0 up to 4096 x 2304 @60Hz DP up to to 7680 x 4320 @60Hz |
| Ethernet | |
| Controller | 2 x Intel® I226-LM 2.5 GbE LAN |
| Audio | |
| Controller | Realtek® ALC888-VD2-GR HD Audio Codec (Co-lay ALC897) |
| H/W Monitor | |
| Watchdog Timer | 256-level Watchdog Timer |
| Smart Fan | N/A |
| TPM | |
| Controller | Infineon SLB9670VQ 2.0 |
| Expansion Slot | |
| M.2 | 1 x M.2 M key (PCIe Gen4 x4 NVMe, SATA 3.0), 2242/2280 1 x M.2 B key (PCIe x1, USB 3.2, USB 2.0 w/NANO SIM-Holder), 2242/3042 1 x M.2 E key (PCIe x1, USB 2.0), 2230 |
| Mini-PCIe | N/A |
| Storage | |
| SATA | 1 x 2.5" SSD (7mm) |
| mSATA | N/A |
| I/O Interface | |
| RJ-45 | 2 |
| PoE | N/A |
| Audio | 1 x Line-out (Mic-in by AP driver) |
| USB | 2 x USB 3.2 Gen2, Type-A 1 x USB 3.2 Gen2, Type-C 2 x USB 2.0, Type-A |
| Serial | 2 x COM ports COM1/2: RS-232/422/485, 0V/5V/12V |
| GPIO | N/A |
| CANBus | N/A |
| HDMI | 2 |
| DVI | N/A |
| DisplayPort | 2 |
| VGA | N/A |
| Antenna | 4 openings reserved for antennas |
| Power Supply | |
| DC Input | DC-in 19V with Lockable DC Jack |
| AC Input | N/A |
| Environment | |
| IP Rating | Full IP40 |
| Operating Temperature |
-10 ~ 50°C (SSD) Note: Thermal Test w/ Airflow:0.7m/s |
| Operating Humidity | 10 ~ 90%, non-condensing |
| Storage Temperature | -20 ~ 80°C |
| Storage Humidity | 10 ~ 90%, non-condensing |
| Vibration | Operating: IEC 60068-2-64: 2 Grms, 5 ~ 500 Hz, 1hr/axis (w/ SSD) |
| Shock | Operating: IEC 60068-2-27: 50G, half sine, 11ms (w/ SSD) |
| Physical characteristics | |
| Dimensions (W x D x H) |
196 x 285 x 29mm |
| Weight | 2.24 kg |
| Mounting | VESA/Wall mount |
| Certification | |
| EMC | FCC Class B, CE, RCM, BSMI, VCCI, UKCA, IC |
| Safety | BSMI |
| Software Platform | |
| OS Support | Windows 10 IoT Enterprise 2021 LTSC (64-bit, 21H2) Windows 11 IoT Enterprise (64-bit, 22H2, Pre-scan) Linux Ubuntu 22.04 (by request) |
