Technical data
| Chassis | ||
|---|---|---|
| HDD/SSD | Front access | Inside access |
| 3 x 5.25" | ||
| 1 x 3.5" | 1 x 3.5" | |
| Dimensions | W. x D. x H. | 481 x 446 x 175 mm |
| Weight | 10.7 kg | |
| Front I/O |
2x USB 1x PS/2 |
|
| Cooling | 12 cm front fan+ 8 cm back fan | |
| Others | Temperature, voltage and fan monitoring | |
| Processor | |
|---|---|
| Processor | Intel® Core™ i9 / i7 / i5 / i3 X gen |
| CPU socket | LGA 1200 |
| RAM | |
| Technology | Dual Channel(Non-ECC) DDR4 2400/2666/2933 |
| Capacity | Up to 64 GB |
| Socket | 2 x 288 - UDIMMs |
| GPU | |
| Controller | Intel® HD Graphics |
| GPU memory | Depends on the selected processor |
| VGA | 1 (Up to 1920 x 1200 @60Hz) |
| DVI-D | 1 (Up to 1920 x 1200 @24Hz) |
| DisplayPort | No |
| Ethernet | |
| Controller | GbE LAN1: Intel I219-V |
| GbE LAN2: Intel I210-AT | |
| H/W Monitor | |
| Watchdog Timer | 255 - level Watchdog Timer |
| Smart Fan | Yes |
| TPM | |
| Controller | Optional, TPM2.0 |
| I/O | |
| USB | 4 x USB 3.2 Gen 1 |
| 2x USB 2.0 front, 2 x USB 2.0 type A | |
| COM |
2 x RS-232 (rear), 3 x RS-232, 1 x RS-232/422/485 |
| Serial | 1 x LPT, 8bit GPIO |
| PS/2 | Optional |
| GPIO | 8-bits |
| Expansion Slots | |
| PCIe x16 | 1 |
| PCIe x4 | 2 |
| PCIe x1 | - |
| PCI | 4 |
| M.2 | 1 |
| Mini-PCIe | - |
| Mass memory | |
| SATA | 4 x SATA 3.0 |
| Working environment | |
| Working temp | -10 ~ 60°C |
| Working humidity | 40 °C @ 95% RH Non-condensing |
| OS Support | Windows 11 Windows 10 (64-bit) Windows 7 (32/64-bit) (Skylake-S Series CPU Only) Windows 8.1 (64-bit) (Skylake-S Series CPU Only) Linux Fedora 23 (by request) Linux Ubuntu 16.04 (by request) |
