Technical data
| Chasiss | |||
|---|---|---|---|
| HDD/SDD | Front access | Inside access | |
| 5.25" | 3 | ||
| 3.5" | 1 | 1 | |
| DImensions | Szer. x Głęb. x Wys. | 481 x 446 x 175 mm | |
| Weight | 10.7 kg | ||
| Front I/O | 4x USB 3.0 | ||
| Cooling | 12 cm front fan+ 8 cm back fan | ||
| Others | Temperature, voltage and fan monitoring | ||
| MODEL | SIGMA 706 |
|---|---|
| Processor | Intel® Core™ i7 / i5 / i3 8th/9th gen. & Celeron/Pentium |
| CPU socket | LGA 1151 |
| RAM | |
| Technology | Dual Channel (Non-ECC) DDR4 2400/2666 |
| Capacity | Up to 32 GB |
| Socket | 2 (288-pin DIMM) |
| GPU | |
| Controller | Intel® HD Graphics |
| GPU memory | Depends on the selected processor |
| VGA | 1 (up to 1920 x 1200 @60Hz) |
| DVI-D | 1 (up to 1920 x 1200 @60Hz) (tylko wersja G2) |
| DisplayPort | - |
| Ethernet | |
| Controller | GbE LAN1: Intel I219-V |
| GbE LAN2: Intel I210-AT (only G2 version) | |
| H/W Monitor | |
| Watchdog Timer | 255 - level Watchdog Timer |
| Smart Fan | Yes |
| TPM | |
| Controller | Optional, TPM2.0 |
| I/O | |
| USB | 2 x USB 3.1, 1, 2 x USB 2.0 (rear) |
| 2 x USB 3.1, 2 x USB 2.0, 1 x USB 2.0 Typ-A (internal connectors) | |
| COM | 2 x RS-232 (VG version) lub 5 x RS-232 + 1 x RS-232/422/485 (G2 version) |
| Serial | 1 x LPT, 8bit GPIO |
| PS/2 | Optional |
| GPIO | 8-bits |
| Expansion Slots | |
| PCIe x16 | 1 |
| PCIe x4 | 1 |
| PCIe x1 | - |
| PCI | 5 |
| M.2 | - |
| Mini-PCIe | - |
| Mass memory | |
| SATA | 4 x SATA 3.0 |
| Working environment | |
| Working temp | -10 ~ 60°C |
| Working humidity | 40 °C @ 95% RH Non-condensing |
| OS Support | Windows 11 Windows 10 (64-bit) Windows 7 (32/64-bit) (Skylake-S Series CPU Only) Windows 8.1 (64-bit) (Skylake-S Series CPU Only) Linux Fedora 23 (by request) Linux Ubuntu 16.04 (by request) |
