Technical data
| Processor | |
| CPU | Intel® Atom Quad Core E3845 Intel® Celeron® Quad Core J1900 Intel® Celeron® Quad Core J3455 |
| CPU clock speed | 1.9 GHz~2 GHz (Depends on CPU) |
| L2 Cache | 2Mb |
| CPU Type | BGA |
| Chipset | SoC |
| BIOS | AMI EFI64 Mbit |
| RAM Memory | |
| Technology | DDR3L 1333 MHz |
| Max. Capacity | Do 8GB |
| Socket | 1 x 204-pin SO-DIMM |
| Display | |
| Controller | Intel® HD Graphics |
| Graphics Memory | Depends on CPU |
| Multiple Display | 2 Independent Displays |
| Interfaces | DP 2.1 do 2560x1440p @60Hz HDMI v1.4 do 1920x1080p @60Hz |
| Ethernet | |
| Controller | Intel i210 GbE, 802.10av, IEEE1588/802.1AS, 803.3az Intel 82583V GbE, 802.10av, IEEE1588/802.1AS, 803.3az (Zależnie od modelu) |
| TPM | |
| Controller | T2.0 |
| Expansion slots | |
| PCIe x16 | N/A |
| PCI | N/A |
| Mini-PCIe | 2 x Full-size |
| Mass memory | |
| SATA | 1x 2.5" HDD |
| mSATA | 1 x |
| M.2 | N/A |
| I/O | |
| Audio | 1 x Line-out |
| USB | 1 x USB 3.0, 3 x USB 2.0 |
| Serial | 4 x RS232/422/485, DB9, 50 ~ 115.2kbps |
| CANbus | N/A |
| HDMI | 1 |
| LVDS | N/A |
| DVI | N/A |
| Display Port | 1 |
| Anten | N/A |
| Power input | |
| DC Input | 1x 1x 3-pin 10V to 36V DC |
| Environment | |
| IP Rating | N/A |
| Working temperature | - 20 ~ 60°C |
| Working humidity | 10 ~ 95%, non-condensation |
| Storage temperature | -40 ~ 85°C |
| Storage humidity | 10 ~ 95%,non-condensation |
| Vibration | IEC 60068-2-64 |
| Shocks | IEC 60068-2-64 |
| Dimensions | |
| Dimensions (W x D x H) | 105 x 105 x 35 mm |
| Mass | 1 kg |
| Mounting | Wall, DIN, VESA |
| Certificates | |
| EMC | UL, CE, FCC, CCC |
| Safety | BSMI |
| Operating System | |
| OS | Microsoft® Windows 7, Windows 10, Advantech Linux |
