Technical data
System | ||
CPU | Core i7 6600U | Core i3 6100U |
Frequency | 2.6 GHz (Dual-Core) | 2.3 GHz (Dual Core) |
L3 Cache | 4MB | 3MB |
BIOS | AMI UEFI 128 Mbit | |
RAM | ||
Technology | DDR4 2133 MHz | |
Max. capacity | 16 GB | |
Socket | 1 x 260-pin SO-DIMM | |
Graphics | ||
Controller | Intel HD Graphics 520 | |
Graphics | DirectX 11.3, OpenGL 4.4, and OpenCL 2.1 Full AVC/ VC1/ MPEG2 HW Decode |
|
VGA | Up to 1920 x 1080 @ 60Hz | |
HDMI | HDMI 1.4a for HD video playback, 4096 x 2160 @ 24Hz | |
Dual display | Yes, VGA + HDMI | |
Optional display | HDMI, DP | |
Triple display | VGA + HDMI + optional module | |
Ethernet | ||
LAN1 | 10/100/1000 Mbps Intel i219 GbE, support Wake On Lan | |
LAN2 | 10/100/1000 Mbps Intel i210 GbE, support Wake On Lan | |
Audio | ||
Interface | Realtek ALC888S, High Definition Audio. Line-out, Mic-in | |
I/O | ||
Serial | 4 x RS-232/422/485 (auto flow control) | |
USB | 4 x USB 3.0, 2 x USB 2.0 | |
DIO | 8bit | |
Other | ||
Watchdog timer | 255 levels timer interval, setup by software | |
Expansions | ||
Mini PCIe | 2 x full size Mini PCIe (1 x SIM holder) | |
iDoor | 1 slot (optional) | |
Storage | ||
HDD / SSD | Kieszeń SATA 2,5" (max. 12,5 mm height) | |
SSD | 1 x full size mSATA (shared with mPCIe) | |
OS Support | ||
Microsoft | Windows 10, Windows 8.1, WES7, Windows 7 | |
Linux | Supported by project | |
Power Requirement | ||
Type | ATX | |
Power input | 12VDC (9-36V optional) | |
Min. power requirements | 12V, 5A | |
Power adaptor | AC na DC, DC12V/5A, 60W (Optional) | |
Power Consumption | ||
Typical | 7.96 Watt | 6.92 Watt |
Max. | 43.28 Watt | 41.72 Watt |
Mechanical | ||
Construction | Aluminum housing | |
Mounting | Din-Rail mounting, Desk/wall-mounting, VESA mounting | |
Dimensions (W x H x D) | 260 x 54 x 140.2 mm (10.24" x 2.13" x 5.52") | |
Weight | 2.3 kg (5.07 lb) | |
Environment | ||
Operating Temperature | With extended temperature peripherals: -20 ~ 60 °C (-4 ~ 140 °F) with 0.7m/s air flow With 2.5-inch hard disk 0 ~ 45 °C (32 ~ 113 °F) with 0.7m/s air flow | |
Storage Temperature | -40 ~ 85 °C ( -40 ~ 185 °F) | |
Relative Humidity | 95% @ 40 °C (non-condensing) | |
Vibration During Operation | SSD: 3 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis | |
Shock During Operation | SSD: 30 G, IEC 60068-2-27, half sine, 11 ms duration | |
EMC | CE/FCC Class B, CCC, BSMI | |
Safety Certifications | UL, CCC, BSMI |
