Dane techniczne
| Jednostka obliczeniowa | |
| CPU | Intel Core i3/i5/i7 8/9 generacji |
| Chipset | Q370/H310 |
| BIOS | AMI 256Mb SPI Flash |
| Pamięć RAM | |
| Technologia | Dual-channel DDR4 2400/2666 MHz (without ECC) |
| Socket | 2 x 260-pin DDR4 SODIMM (up to 32GB per socket) |
| Max. pojemność | 64GB |
| Układ graficzny | |
| Chipset | Q370: Intel® HD Graphics 630, supports DirectX 12 H310: Intel® HD Graphics 610, supports DirectX 12 |
| VGA | 1 x DB15, up to 1920 x 1200 maximum resolution |
| HDMI | 1 x HDMI, up to 4096 x 2160@30Hz (with optional expansion cable for 2nd HDMI or 1 x DVI connector) |
| Multiple Display | Q370: 3 x independent displays (third display output via optional cable) H310: 2 x independent displays |
| Ethernet | |
| Kontroler | Q370 LAN1: Intel® I219LM, LAN2: Intel® i210IT H310 LAN1: Intel® I219V, LAN2: Intel® i210IT |
| Interfejs | 2 x RJ45 |
| Pamięć masowa | |
| HDD | 1 x 2.5" HDD/SSD |
| mSATA | 1 |
| RAID | 0/1/5/10 (MIC-770Q only) |
| I/O | |
| USB | Q370: 2 x USB3.1, 6 x USB3.0 and 1 x internal USB 2.0 H310: 4 x USB 3.0 and 4 x USB 2.0 |
| Porty szeregowe | 2 x DB9, 2 x RS-232/422/485 support auto flow control; 4 x RS-232 (Optional) |
| Audio | 2 (1 x line out and 1 x mic in) |
| Rozszerzenia | |
| Moduły rozszerzeń | Wsparcie dla i-Modules Advantech |
| Mini PCIe | Q370: 1 x mini PCIe (via USIM), 1 x mini PCIe/mSATA H310: 1 x mini PCIe (via USIM), 1 x mSATA |
| Monitoring parametrów i uruchamianie | |
| LED | 2 (1 x Storage and 1 x Power), 4 for COM1 TX/RX and COM2 TX/RX |
| Button | 1 x Power on/off switch |
| Remote Switch | Yes, 2pin terminal block (Optional) |
| Zasilanie | |
| Typ | ATX/AT |
| Napięcie wejściowe | 9 ~ 36 VDC |
| Pobór mocy | Typowe: 32W Max: 116W |
| Watchdog Timer | |
| Watchdog | 255 levels timer interval, setup by software |
| Środowisko pracy | |
| Temperatura | 65W CPU w/ industrial SSD: -10 ~ 40 °C with 0.7 m/s air flow 35W CPU w/ industrial SSD: -10 ~ 50 °C with 0.7 m/s air flow Non-operating: -40 ~ 85 °C |
| Wilgotność | 95% @ 40 °C (non-condensing) |
| Wibracje | SSD: 3 Grms @ 5 ~ 500 Hz, random, 1 hr/axis 2.5" HDD: 1 Grms @ 5 ~ 500 Hz, random, 1 hr/axis |
| Wstrząsy | SSD: 20G, IEC-68-2-27, half-sine wave, 11 ms duration |
| Cechy mechaniczne | |
| Wymiary (Szer. x Wys. x Głęb.) | 77 x 192 x 230 mm |
| Masa | 2.8 kg |
| Mocowanie | Desktop / naściennie |
| Certyfikaty | |
| EMC | CE/FCC Class A, CCC, BSMI |
| Bezpieczeństwo | CB/UL, CCC, BSMI |
| Wsparcie OS | |
| System operacyjny | Windows 10, Windows 10 IoT, Windows Server 2016/2019 (with Win 10 drivers), Windows 11, Linux OS |
