Technical data
| Chassis | ||
|---|---|---|
| Drive Bay | External | Internal |
| 2 x 5.25" | - | |
| 1 x 3.5" | 1 x 3.5" | |
| Dimensions (W. x D. x H.) |
200 x 320 x 480 mm | |
| Weight | 14 kg | |
| Front I/O Panel | 2 x USB i PS/2 | |
| Cooling | 12 cm Fan & Air Filters | |
| Other | Temperature, Fan, Voltage Monitoring | |
| Processor | |
|---|---|
| Processor | Intel® Core™ i9 / i7 / i5 / i3 12th/13th/14th gen. |
| CPU Socket | LGA 1700 |
| RAM | |
| Technology | Dual Channel(Non-ECC) DDR4 3200 |
| Capacity | Do 64 GB |
| Socket | 2 x 288-pin DIMM |
| Graphics | |
| Controller | Intel® HD Graphics |
| Graphics Memory | Depends on selected processor |
| VGA | 1 (do 1920 x 1200 @60Hz) |
| HDMI | 1 (G2 ver.) (do 4096 x 2304 @ 30Hz) |
| DisplayPort | - |
| Ethernet | |
| Ports | 2 |
| H/W Monitor | |
| Watchdog Timer | 255 - level Watchdog Timer |
| TPM | |
| Controller | Optional, dTPM2.0 |
| I/O | |
| USB | 4 x USB 3.2 Gen 1 |
| 2x USB 2.0 front, 2 x USB 2.0 type A | |
| COM | 3 x RS-232, 1 x RS-232/422/485 |
| Parallel | 8bit GPIO |
| Expansions | |
| PCIe x16 | 1 |
| PCIe x4 | 2 |
| PCIe x1 | - |
| PCI | 4 |
| M.2 | 1 |
| Mini-PCIe | - |
| Mass memory | |
| SATA | 4 x SATA |
| Environment | |
| Working temp. | -10 ~ 60°C |
| Working humidity | 95%, non condensing |
| OS | Windows 10 Windows 11 |
