Technical data
| CPU | |
| CPU | Intel® 11th Gen Core™ i CPU |
| BIOS | AMI EFI 256 Mbit |
| RAM | |
| Technology | DDR4 3200 MHz |
| Socket | 2 x Dual Channel DDR4 3200 MHz 260 pin SO-DIMM (no support ECC) |
| Max. capacity | 64GB |
| Graphics | |
| Chipset | Intel® Iris® Xe graphics |
| VGA | Up to 1920 x 1200 @ 60Hz |
| HDMI | Up to 4096 x 2160 @ 60Hz |
| Dual Display | HDMI+VGA |
| Ethernet | |
| LAN1 | 10/100/1000/2500 Mbps Intel i225 GbE,support Wake On LAN |
| LAN2 | 10/100/1000 Mbps Intel i219 GbE,support Wake On LAN |
| LAN3 | 10/100/1000/2500 Mbps Intel i225 GbE,support Wake On LAN |
| Storage | |
| SSD/HDD | 1 x 2.5" SATAIII Drive bay |
| mSATA | 1 x Full-size mSATA |
| I/O | |
| USB | 3 x USB 3.2, 3 x USB 2.0, 1 x internal USB 2.0 supported by project |
| Serial ports |
4 x RS-232/422/485 |
| GPIO | 8-bit Programmable DIO |
| CANBus | Optional (supported by project) |
| Audio | |
| Interface | Realtek ALC888S, High Defination Audio, Mic-in or Line-out |
| Expansions | |
| Mini PCIe | 1 x Full-size mPCIe |
| M.2 | 1 x M2. 2230 E key and 1 x M.2 2280 B key with nano SIM holder |
| Power supply | |
| Type | ATX/AT |
| Input voltage | 12 ~ 24 VDC |
| Power requirements | Typical: 19.8W for Core i5-1145G7E, 18W for Core i3-1115G4E Max: 35.1W for Core i5-1145G7E, 30.6W for Core i3-1115G4E |
| Watchdog Timer | |
| Watchdog | 255 levels timer interval, setup by software |
| Environment | |
|
Working temp. |
With extended temp. peripherals: -40 ~ 60° C with 0.7m/s air flow |
|
Storage temp. |
-40 ~ 85 °C (-40 ~ 185°F) |
| Humidity | 95% @ 40 °C (non-condensing) |
| Vibrations during Operation | With SSD: 3 Grms, IEC60068-2-64, random, 5~500 Hz, 1hr/axis (with Wall Mount) |
| Shock during Operation | With SSD: 30 G, IEC-60068-2-27, half sine, 11 ms duration (with Wall Mount) |
| Mechanical properties | |
| Dimensions (W x H x D) |
60 x 173 x 141 mm |
| Weight | 1.5 kg |
| Mounting | DIN-rail/ wall |
| Certificates | |
| EMC | CE/FCC Class B, CCC |
| Safety | UL, CB, CCC |
| OS Support | |
| OS | Windows 10 Enterprise, Windows 11, Linux Ubuntu 20.04 |
