Technical data
MODEL | DELTA 4XX |
---|---|
Processor | Intel® Core™ i7 / i5 / i3 VIIth gen. |
Socket | LGA 1151 |
RAM | |
Technology |
Dual Channel (Non-ECC) DDR4 2400/2666 |
Capacity | Up to 16 GB |
Socket | 1 x SO-DIMM |
Display | |
Size | 12.1" |
Resolution | 1024x768 |
Luminance (cd/m2) | 600 |
Contrast | 1000:1 |
Angles | 89 (left), 89 (right), 89 (up), 89 (down) |
Touch type | 5-wire, resistive |
Ethernet | |
LAN |
2 x 10/100/1000Base-T |
H/W Monitor | |
Watchdog Timer | 255 - level Watchdog Timer |
I/O | |
USB |
4 x USB 3.0 |
COM |
2 x RS-232, 1 x RS-422/485 |
VGA | 1 x DB15 |
DIsplayPort | 1 |
Audio | 1 x Audio line out/ mic in |
Expansions | |
M.2 | 1 |
Mini-PCIe | 1 |
Storage | |
SATA | 1 x 2.5" SSD/HDD |
Environment | |
Working temp. | 0 ~ 50°C |
Humidity | 10 ~ 95%, non-condensing |
IP | IP65 |
OS | Microsoft® Windows 10 (64-bit), Win 10 LTSC, Linux |
Physical properties | |
Dimensions | 317 x 246 x 60.5 mm |
Weight | 3.4kg |
Mounting | VESA |
Certificates | CE, FCC Class B, BSMI |
