Technical data
| MODEL | DELTA 4XX |
|---|---|
| Processor | Intel® Core™ i7 / i5 / i3 VIIth gen. |
| Socket | LGA 1151 |
| RAM | |
| Technology |
Dual Channel (Non-ECC) DDR4 2400/2666 |
| Capacity | Up to 16 GB |
| Socket | 1 x SO-DIMM |
| Display | |
| Size | 12.1" |
| Resolution | 1024x768 |
| Luminance (cd/m2) | 600 |
| Contrast | 1000:1 |
| Angles | 89 (left), 89 (right), 89 (up), 89 (down) |
| Touch type | 5-wire, resistive |
| Ethernet | |
| LAN |
2 x 10/100/1000Base-T |
| H/W Monitor | |
| Watchdog Timer | 255 - level Watchdog Timer |
| I/O | |
| USB |
4 x USB 3.0 |
| COM |
2 x RS-232, 1 x RS-422/485 |
| VGA | 1 x DB15 |
| DIsplayPort | 1 |
| Audio | 1 x Audio line out/ mic in |
| Expansions | |
| M.2 | 1 |
| Mini-PCIe | 1 |
| Storage | |
| SATA | 1 x 2.5" SSD/HDD |
| Environment | |
| Working temp. | 0 ~ 50°C |
| Humidity | 10 ~ 95%, non-condensing |
| IP | IP65 |
| OS | Microsoft® Windows 10 (64-bit), Win 10 LTSC, Linux |
| Physical properties | |
| Dimensions | 317 x 246 x 60.5 mm |
| Weight | 3.4kg |
| Mounting | VESA |
| Certificates | CE, FCC Class B, BSMI |
